Процессор
Производитель процессора
The manufacturer that produced the processor.
Intel
Сокет процессора
Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.
LGA 1700
Совместимые серии процессоров
A processor which is compatible with this device
Процессор Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Процессор Intel® Pentium®
Поддерживаемые сокеты процессоров
The sockets (plugs) for processors that are supported (can be used) by the device.
LGA 1700
Память
Поддерживаемые типы памяти
Types of memory which can be used with the product.
DDR5-SDRAM
Количество слотов памяти
4
Тип слотов памяти
A memory slot
DIMM
Каналы памяти
Dual-channel
ECC сompatibility
ECC и без ECC
Поддерживаемые частоты памяти
Memory clock speed is the time it takes for a computer to complete basic operations. It refers to the computer's processing speed and is measured in hertz. It is however not such a reliable measure of a computer's speed as it doesn't take into account other factors like RAM and cache size.
4400, 4800, 5200, 5600 MHz
Supported memory clock speed (max)
5600 MHz
Максимальная внутренняя память
The maximum internal memory which is available in the product.
256 GB
Небуферизованная память
Maximum internal memory per slot
64 GB
Контроллеры хранения данных
Поддерживаемые типы накопителей
The type of storage drives the device is compatible with.
HDD & SSD
Поддерживаемые интерфейсы носителя
M.2, PCI Express 4.0, SATA III
Количество поддерживаемых жестких дисков
The total number of hard drives that can be used in/with this product.
4
Количество поддерживаемых дисков памяти
How many storage drives can be fit into the product at once.
7
Поддержка RAID
The device uses RAID
Уровни RAID
RAID is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways
0, 1, 5, 10
Графический адаптер
Поддержка технологии параллельной обработки
Parallel processing technology is the simultaneous use of more than one CPU or processor core to execute a program or multiple computational threads. Ideally
Не поддерживается
Максимальное разрешение
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height
4096 x 2304 пикселей
HDCP
High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
Версия DirectX
DirectX is a collection of APIs (application programming interfaces) for easily handling tasks related to game programming on the Microsoft Windows operating system.
12.0
Внутренние порты
Разъемы USB 2.0
The end of a cable with a USB 2.0 connector. USB 2.0 was released in April 2000 (now called "Hi-Speed")
2
Разъемы USB 3.2 Gen 1 (3.1 Gen 1)
This is a connector (normally attached to a cable) for USB 3.0. USB 3.0 is the second major revision of the Universal Serial Bus (USB) standard for computer connectivity. First introduced in 2008
1
Разъемы USB 3.2 Gen 2 (3.1 Gen 2)
1
Количество разъемов SATA III
Serial ATA (Advanced Technology Attachment) (SATA) is a computer bus interface that connects host bus adapters to mass storage devices such as hard disk drives and optical drives. SATA III (revision 3.x) interface
4
Разъем выхода S/PDIF
Аудиоразъем передней панели
Разъем передней панели
Разъем питания ATX (24-конт.)
Разъем вентилятора центрального процессора
Number of CPU fan connectors
2
Количество разъемов вентилятора корпуса
4
EPS разъем питания (8-конт)
Number of EPS power connectors (8-pin)
1
TPM коннектор
Коннекторы последовательного порта
1
12В разъем питания
Number of water pump connectors
2
RGB LED контактный разъем
Number of RGB LED pin headers
4
Порты на задней панели
Количество портов USB 2.0
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed")
5
Количество портов USB 3.2 Gen 1 (3.1 Gen 1) Type-A
1
Количество портов USB 3.2 Gen 1 (3.1 Gen 1) Type-С
Number of USB 3.0 (3.1 Gen 1) ports with Type-C connector. USB 3.0 (3.1 Gen 1) is USB interface version which supports transfer rate up to 5 Gbit/s (SuperSpeed). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.
1
Количество портов USB 3.2 Gen 2 (3.1 Gen 2) Type-A
1
Количество портов Ethernet LAN ( RJ-45)
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
Количество HDMI портов
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor
1
Версия HDMI
2.1
Количество портов DisplayPort
Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor
1
Версия DisplayPort
1.2
Линейные выходы наушников
Number of sockets /ports where headphones are connected.
1
Порты на задней панели
Вход линии
Линейный вход микрофона
The socket where a microphone is connected to the device.
Сеть
Подключение Ethernet
An Ethernet LAN (Local Area Network) interface is present
Тип Ethernet интерфейса
2.5 Gigabit Ethernet
Контроллер LAN
Realtek RTL8125
Wi-Fi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Свойства
Чипсет материнской платы
The chipset connects the microprocessor to the rest of the motherboard.
Intel B760
Аудио чип
Realtek ALC897
Выходные звуковые каналы
An audio output channel is an electric circuit which acts as a path for a signal produced by a device. A device may have several audio output channels.
7.1 канала
Цвет товара
Цвет продукции, например: красный, синий, зеленый, черный, белый.
Темно-коричневый
Мониторинг состояния ПК
Вентилятор, Температура, Напряжение, Water cooling
Комплектующие для
What this product is used as a part of (component for).
ПК
Формат материнской платы
Design of the motherboard (ATX
ATX
Семейство чипсета материнской платы
The category of motherboard chipset e.g. Intel
Intel
Тип охлаждения
The method used to cool the device or to cool the air around the device.
Пассивный
Тип источника питания
What the power source is.
ATX
Поддерживаемые операционные системы Windows
Windows vesions wich can be used with the device.
Windows 10 x64, Windows 11 x64
Слоты расширения
Слоты PCI Express x16 (поколение 3.x)
Places where PCI Express x16 (Gen 3.x) are placed inside and connected to the computer motherboard.
2
PCI Express x16 (Gen 5.x) slots
1
Количество M.2 (M) слотов
3
1st M.2 largest key size
22110
1st M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
22110
2nd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
22110
3rd M.2 highest PCI Express generation
4.0
BIOS
Тип BIOS
The BIOS (Basic Input/Output System) initializes and tests system hardware components
UEFI AMI
Размер памяти BIOS
256 Mbit
Версия ACPI
5.0
Перемычка Clear CMOS
Desktop Management Interface (DMI) версия
2.7
Версия BIOS (SMBIOS)
2.7
Логистические данные
Страна производства
Country where the device is made. Aka Country of manufacture (COM).
Китай
Количество в транспортировочной упаковке
1 шт
Батарея
Вес батареи
3 g
Вес лития на батарею
0,07 g
Количество элементов аккумулятора
1
Технология батареи
The type of battery in the device
Lithium-Manganese Dioxide (LiMnO2)
Тип батареек
Description of battery supplied with the product
CR2032
Данные об упаковке
Ширина упаковки
The distance from one side of the packaging to the other.
335 mm
Глубина упаковки
The distance from the front to the back of the packaging.
270 mm
Высота упаковки
The distance from the top to the bottom of the packaging.
80 mm
Масса брутто
Weight of the packaged product.
1,8 kg
Вес и размеры
Ширина
The measurement or extent of something from side to side.
305 mm
Глубина
The distance from the front to the back of something.
244 mm
Высота
The measurement of the product from head to foot or from base to top.
35 mm
Содержимое упаковки
Батарейки в комплекте
Винты в комплекте
Поставляемое ПО
Software distributed with another product such as a piece of computer hardware or other electronic device
Norton® Internet Security (OEM version)
Прочие свойства
Вес
Weight of the product without packaging (net weight). If possible
1,56 kg
